METALEX CNC HYDRAULIC PRESS BRAKE

DELEM DA-66T Features
1. 17" colour TFT touch screen
2. Full screen touch control
3. 2D graphic program by touch
screen control
4. 3D product graph display
5. Automatic collision detection
6. Automatic sequence computation
7. One page programming table
8. Graphic tooling library
(graphic program & display)
9. Tooling safety zone
10. 16 axes available
DELEM DA-58T Features
1. 15" colour TFT touch screen
2. Full screen touch control
3. 2D graphic programming by touch
screen control
4. 3D product graph display
5. Automatic sequence computation
6. Automatic collision detection
7. One page programming table
8. Graphic tooling Ibrary
CNCPB-12032 (graphic program & display)
9. Tooling safety zone
10.5 axes available
CNC Hydraulic Press Brake Standard Accessories (4 Axes)

CNC Hydraulic Press Brake Optional Accessories

DA-66T/DA-58T CNC Specification(4Axes)
CNCPB-15025 CNCPB-20032
CNCPB-25042
Model CNCPB-5016 CNCPB-6020 CNCPB-8020 CNCPB-10025 CNCPB-12025 CNCPB-15032 CNCPB-20042 CNCPB-25032
CNCPB-10032
CNCPB-12032 CNCPB-15042 CNCPB-20050
CNCPB-8025
CNCPB-10042
CNCPB-25050
CNCPB-15050 CNCPB-20060
6.0x4200
5.8x3200
7.0x4200
3.5x3200
Capacity (SS400) (mm) 3.5x1600 4.0x2000 5.0x2000 4.5x2500 5.5x2500 7.0x2500 7.0x3200 8.0x3200
5.0x5000
4.0x2500
4.0x3200
4.5x4200
3.0x4200
5.5x5000
3.5x5000
4.0x6000
Max. Pressure (Ton) 50 60 80 100 120 150 200 250
Motor (HP) 7.5 7.5 10 15 15 20 25 25
4200
3200
3000
Table Length (mm) 1600 2000 2000 2500 2500 2500 3200 2000
3200
2500
5000
4200
3200
4200
4000
6000
5000
Table Width (mm) 100 100 100 100 100 100 150 150
2600
Distance Between 1220 1600 1600 2100 2100 2020 2600 3200
3400
2600
4200
Housing (mm) 2100 3400 2600 3400 4200 5000
5200
4200
Daylight (mm) 450 450 450 450 450 450 450 550
Stroke (mm) 250 250 250 250 250 250 250 300
Throat (mm) 400 400 400 400 400 400 400 400
Lowering Speed (mm/s) 180 180 180 180 180 180 180 180
Pressing Speed (mm/s) 1-10 1-10 1-10 1-10 1-10 1-10 1-10 1-10
Return Speed (mm/s) 160 160 160 160 160 160 160 160
CNCPB-30032 CNCPB-40032 CNCPB-50042 CNCPB-60042
Model CNCPB-30042 CNCPB-40042 CNCPB-50050 CNCPB-60050 CNCPB-70050 CNCPB-80050 CNCPB-90050 CNCPB-100050
CNCPB-70060 CNCPB-80060 CNCPB-90060 CNCPB-100060
CNCPB-30050 CNCPB-40050
CNCPB-30060 CNCPB-40060 CNCPB-50060 CNCPB-60060
11x3200 15x3200 15x4200 18x4200
Capacity (SS400) (mm) 8.5x4200 12x4200 12x5000 15x5000 18x5000 20x5000 22x5000 25x5000
7.0x5000
14x6000
20x6000
16x6000
10x5000
18x6000
6.0x6000 8.6x6000 10x6000 12x6000
Max. Pressure (Ton) 300 400 500 600 700 800 900 1000
Motor (HP) 40 50 60 60 75 100 100 125
3200 3200 4200 4200
Table Length (mm) 4200 4200 5000 5000 5000 5000 5000 4000
5000
6000
6000
5000
5000
6000
6000 6000 6000 6000
Table Width (mm) 150 150 300 300 300 300 300 300
2600 2600
Distance Blowing 3200 3200 3200 3200 4000 4000 4000 5000
4000
4000
Housing (mm) 4000 4000 5000 5000 5000 5000 5000 6000
5000 5000
Daylight (mm) 550 550 550 600 600 600 600 600
Stroke (mm) 300 300 300 350 350 350 350 350
Throat (mm) 400 400 400 400 400 400 400 400
Lowering Speed (mm/ 100 100 100 100 100 100 100 100
s)
Pressing Speed (mm/s) 1-10 1-7 1-6 1-6 1-6 1-6 1-6 1-6
Return Speed (mm/s) 90 90 70 70 65 65 60 60
