METALEX NC HYDRAULIC GUILLOTINE SHEAR

NCGS-25040HM

HM FUNCTIONS Manual Blade Gap Adjustment Device
1. Manual Blade Gap Aujustment
2. Motorized Cutting Length Adjustment ※UPPER/LOWER BLADE EACH FOUR
3. Motorized Back Gange Adjustment CUTTING EDGES AVAILABLE
4. Back Giauge Travelling: 800mm
5. Buck Gauge Accuracy:+/-0.1mm
6. Counter. 1-9999

NCGS-15045H NCGS-15065H NCGS-150100H
NCGS-20045H NCGS-20065H NCGS-25080H NCGS-250130H
NCGS-25045H NCGS-25065H NCGS-31080H NCGS-250100H NCGS-310130H
Type (model) NCGS-31045H NCGS-31065H NCGS-41080H NCGS-310100H NCGS-410130H
NCGS-41045H NCGS-41065H NCGS-61080H NCGS-410100H NCGS-610130H
NCGS-610100H
NCGS-61045H NCGS-61065H
1550 1550 1550
2000 2000 2500 2500
2500 2500 3100 2500 3100
Shearing Length (mm) 3100
3100 3100 4100 4100 4100
4100 4100 6100 6100 6100
6100 6100
Max.Thickness (SS400) (mm) 4.5 6.5 8.0 10 13
Stainess Steel Thickness (SUS304) 3.0 4.0 5.0 6.5 8.5
(mm)
Throat (mm) 100 100 100 100 100
Max.Angle (SS400) 2° 2° 2° 30' 2° 30' 2° 30'
27-35 26-34 22-30
26-34 25-33 18-26 18-26 15-21
25-33 24-32 15-23 13-19
Shear/Min 15-23
24-32 21-29 12-20 10-16
17-25 15-23 7-15 12-20 7-13
7-15
11-19 11-19
9 9
11 11 13 9 13
13 13 16 13 16
Hold-Down Bean Cylinder (PC) 16
16 16 21 21 21
21 21 30 30 30
30 30
10 15 30
10 15 25 30 40
10 15 25 40
Main Motor (HP) 30
15 20 30 40 50
15 25 40 50 75
20 30
Backgauge Stroke (mm) 800 800 800 800 800
